Spin-based quantum information processing makes extensive use of spin-state manipulation. This ranges from dynamical decoupling of nuclear spins in quantum sensing experiments to applying logical gates on qubits in a quantum processor. Fast manipulation of spin states is highly desirable for accelerating experiments, enhancing sensitivity, and applying elaborate pulse sequences. Strong driving using intense radio-frequency (RF) fields can, therefore, facilitate fast manipulation and enable broadband excitation of spin species. In this work, we present an antenna for strong driving in quantum sensing experiments and theoretically address challenges of the strong driving regime. First, we designed and implemented a micron-scale planar spiral RF antenna capable of delivering intense fields to a sample. The planar antenna is tailored for quantum sensing experiments using the diamond\u2019s nitrogen-vacancy (NV) center and should be applicable to other solid-state defects. The antenna has a broad bandwidth of 22 MHz, is compatible with scanning probes, and is suitable for cryogenic and ultrahigh vacuum conditions. We measure the magnetic field induced by the antenna and estimate a field-to-current ratio of 113 ± 16 G/A, representing a six-fold increase in efficiency compared to the state-of-the-art, crucial for cryogenic experiments. We demonstrate the antenna by driving Rabi oscillations in ¹H spins of an organic sample on the diamond surface and measure ¹H Rabi frequencies of over 500 kHz, i.e. π -pulses shorter than 1 μ s \u2014an order of magnitude faster than previously reported in NV-based nuclear magnetic resonance (NMR). Finally, we discuss the implications of driving spins with a field tilted from the transverse plane in a regime where the driving amplitude is comparable to the spin-state splitting, such that the rotating wave approximation does not describe the dynamics well. We present a simple recipe to optimize pulse fidelity in this regime based on a phase and offset-shifted sine drive, which may be optimized in situ without numerical optimization procedures or precise modeling of the experiment. We consider this approach in a range of driving amplitudes and show that it is particularly efficient in the case of a tilted driving field. The results presented here constitute a foundation for implementing fast nuclear spin control in various systems.

Characterizing the time over which quantum coherence survives is critical for any implementation of quantum bits, memories, and sensors. The usual method for determining a quantum system's decoherence rate involves a suite of experiments probing the entire expected range of this parameter, and extracting the resulting estimation in postprocessing. Here we present an adaptive multiparameter Bayesian approach, based on a simple analytical update rule, to estimate the key decoherence timescales (T1, T2∗ - , and T2) and the corresponding decay exponent of a quantum system in real time, using information gained in preceding experiments. This approach reduces the time required to reach a given uncertainty by a factor up to an order of magnitude, depending on the specific experiment, compared to the standard protocol of curve fitting. A further speedup of a factor approximately 2 can be realized by performing our optimization with respect to sensitivity as opposed to variance.

To use batteries as large-scale energy storage systems it is necessary to measure and understand their degradation in-situ and in-operando. As a battery\u2019s degradation is often the result of molecular processes inside the electrolyte, a sensing platform which allows to measure the ions with a high spatial resolution is needed. Primary candidates for such a platform are NV-centers in diamonds. We propose to use a single NV-center to deduce the electric field distribution generated by the ions inside the electrolyte through microwave pulse sequences. We show that the electric field can be reconstructed with great accuracy by using a protocol which includes different variations of the free induction decay to obtain the mean electric field components and a pulse sequence consisting of three polarized π-pulses to measure the electric field\u2019s standard deviation σ E . From a semi-analytical ansatz we find that for a lithium ion battery there is a direct relationship between σ E and the ionic concentration. Our results show that it is therefore possible to use NV-centers as sensors to measure both the electric field distribution and the local ionic concentration inside electrolytes.
