Titan Themis-Z (Thermo fisher Scientific)

TEM

Titan Themis-Z (Thermo fisher Scientific)

The Thermo Fisher Scientific Themis Z is an ultra-high resolution, double aberration-corrected, transmission electron microscope for analytical scanning probe and wide-field microscopy delivering ultimate optical performance and flexibility. This high-end analytical (S)TEM is…

Gemini SEM 500 (Zeiss)

SEM

Gemini SEM 500 (Zeiss)

The Gemini SEM 500 is a high-resolution SEM. It works both at high vacuum mode and low vacuum modes. It is equipped with various detectors; the E-T detector collects SE2 electrons and provides topographical information, the new high efficiency in-lens detector collects SE1…

Crossbeam 550 FIB/SEM dual beam microscope (Zeiss)

FIB/SEM

Crossbeam 550 FIB/SEM dual beam microscope (Zeiss)

Crossbeam 550 (Zeiss) is a dual-beam Focused ion beam - Scanning electron (FIB-SEM) instrument.

3D imaging of biological samples of cells and tissues at isotropic resolutions down to 5 nm at room temperature and at cryo conditions

Cryo lamellae preparation for cryo STEM…

PALM/STORM Vutara 352 Super Resolution Microscope (Bruker)

Light Microscopy

PALM/STORM Vutara 352 Super Resolution Microscope (Bruker)

Vutara SR-352 (Bruker) super resolution microscope is based on single molecule localization techniques (PALM, STORM, etc.). It enables 3D quantitative imaging at the nanoscale, 10 times or better than that of conventional light microscopes.

It contains four microscopes in one

…

Xradia Versa 520 (Zeiss)

Micro CT (XRM)

Xradia Versa 520 (Zeiss)

The Xradia Versa 520 instrument is designed to provide X-ray tomographic images with up to 600 nm resolution. Complete 3D images without missing wedge of samples up to 14 cm in size are obtained by taking a complete set of projection images while the sample rotates 180 or 360…

Titan Krios G3i (Thermo Fisher Scientific)

TEM

Titan Krios G3i (Thermo Fisher Scientific)

Titan Krios G3i S/TEM microscope from Thermo Fisher Scientific (TFS) is used for advanced, high-throughput, high-resolution 3D imaging and structural elucidation of proteins, cells and other biological specimens by cryo-TEM single particle analysis, and cryo-(S)TEM tomography. It…

Quattro S- environmental SEM (Thermo Fisher Scientific)

SEM

Quattro S- environmental SEM (Thermo Fisher Scientific)

The Quattro environmental SEM is a special microscope that can be operated under various vacuum levels and environments (N₂, water vapor). It enables imaging of wet, oily, dirty, outgassing and non-conductive samples in their natural state without significant sample modification…

Helios 600 FIB/SEM dual beam Microscope (Thermo Fisher Scientific)

FIB/SEM

Helios 600 FIB/SEM dual beam Microscope (Thermo Fisher Scientific)

Dual beam FIB-SEM is a multifunctional analytical instrument integrating both a focused ion beam (FIB) and a scanning electron microscope (SEM) in a single system. This tool offers a number of key techniques and applications: FIB site specific cross sectioning and SEM inspection…

Opterra II Confocal Microscope (Bruker)

Light Microscopy

Opterra II Confocal Microscope (Bruker)

Opterra II (Bruker) is a swept-field confocal microscope utilizes proprietary one-dimensional pinhole array technology to combine the resolution of traditional confocal systems with the speed typically associated with wide-field imaging.

Characteristics & Accessories

FRAP

…

Xradia Micro-XCT 400 (Zeiss)

Micro CT (XRM)

Xradia Micro-XCT 400 (Zeiss)

The Xradia Micro-CT instrument is designed to provide high resolution X-ray tomographic images up to 1 µm resolution. Complete 3D images without missing wedge of samples up to 5 cm in size can be obtained by taking a complete set of projection images while the sample rotates 180…

Talos Arctica (Thermo fisher Scientific)

TEM

Talos Arctica (Thermo fisher Scientific)

Talos Arctica S/TEM microscope from Thermo Fisher Scientific (TFS) is used for advanced, high-throughput imaging, efficient screening of cryo-EM samples, 3D structural elucidation of cells and other biological specimens by cryo-STEM tomography, and electron diffraction. It…

Sigma 500 SEM (Zeiss)

SEM

Sigma 500 SEM (Zeiss)

The Zeiss Sigma 500 is a high resolution SEM. It is equipped with several detectors; the new generation E-T detector can filter out SE3 electrons, thus it collects mainly SE2 electrons and provide topographical information, the in-lens detector collects SE1 and provide high…

Cryo CLEM Fluorescence Microscope (Leica)

Light Microscopy

Cryo CLEM Fluorescence Microscope (Leica)

Cryo CLEM Fluorescence Microscope (Leica) is a widefield light microscope for Correlative Light and Electron Microscopy (CLEM) at cryogenic temperatures. It is equipped with LAS X Cryo CLEM software that automatically scans the sample and generates a high-resolution overview…

RX DeskTom micro CT (Rx solutions)

Micro CT (XRM)

RX DeskTom micro CT (Rx solutions)

The RX DeskTom micro CT instrument is designed to take medium resolution tomographic X-ray images of samples up to 20 cm in size. It completes the high-resolution Xradia instrument by offering scans with higher speed and larger field of view. With this instrument, 4D images of…

Talos F200X G2 (Thermo Fisher Scientific)

TEM

Talos F200X G2 (Thermo Fisher Scientific)

The Talos F200X Transmission Electron Microscope can achieve atomic resolution mode quickly due to the stability of the instrument, which provides high throughput at all operation levels. It is equipped with a high speed camera and high speed energy dispersive X-ray spectroscopy…

Supra 55 (Zeiss)

SEM

Supra 55 (Zeiss)

The Zeiss Supra 55 is a high-resolution SEM. It is equipped with several detectors; the E-T detector collects SE2 electrons and provides topographical information, the in-lens detector collects SE1 electrons and provides high-resolution surface information, the AsB detector…

Cryo-CLEM Fluorescence Microscope (Linkam)

Light Microscopy

Cryo-CLEM Fluorescence Microscope (Linkam)

The cryo-light fluorescent microscope enables imaging at cryogenic temperature conditions for the correlation with cryo electron microscopy. It is equipped with LED light source at several wavelengths and a cryo-stage to hold the sample under cryo conditions. It is designed to…

Tecnai G2 F20 (Twin) TEM/STEM

TEM

Tecnai G2 F20 (Twin) TEM/STEM

The FEI Tecnai G2 F20 S/TEM microscope is used for advanced biological EM imaging, chemical analysis, and 3D structural elucidation by TEM and STEM tomography, including of cryo-preserved specimens.

Characteristics & Accessories

Accelerating voltage: 120-200 kV.

E-beam…

Ultra 55 (Zeiss)

SEM

Ultra 55 (Zeiss)

The Zeiss Ultra 55 is a high resolution SEM. It is equipped with several detectors; the E-T detector collects all types of secondary electrons and provides topographical information, the in-lens detector collects mostly SE1 electrons and provides high-resolution surface…

Axio Zoom V16 (Zeiss)

Light Microscopy

Axio Zoom V16 (Zeiss)

Axio Zoom V16 (ZEISS) is a motorized fluorescence stereo zoom microscope for Correlative Light and Electron Microscopy (CLEM). It is equipped with Zen software that allows multi-channel fluorescence, Z stack and time lapse imaging, in addition to tiles and positions recording.
…

Tecnai Spirit (Bio Twin) TEM (Thermo Fisher Scientific)

TEM

Tecnai Spirit (Bio Twin) TEM (Thermo Fisher Scientific)

The Thermo Fisher Scientific Spirit TEM microscope is ideal for imaging biological cells and tissues that have been fixed, embedded and stained. The “Bio-Twin” lens configuration provides extremely high contrast, and the ability to observe at extremely low magnifications with the…

Revolve (ECHO)

Light Microscopy

Revolve (ECHO)

Revolve is a hybrid microscope, combining upright, inverted, transmitted light and fluorescence.
It is equipped with LED illumination.

Tecnai T12 (Twin) TEM (Thermo Fisher Scientific)

TEM

Tecnai T12 (Twin) TEM (Thermo Fisher Scientific)

The Thermo Fisher Scientific Tecnai T12 TEM microscope is used for imaging biological cells and tissues as well as for cryoTEM of biological macromolecules and soft materials. Cryo-blades provide contamination-free environment for observing cryo-preserved specimens. A high…

ZOE Fluorescent Cell Imager (Bio Rad)

Light Microscopy

ZOE Fluorescent Cell Imager (Bio Rad)

The ZOE Cell Imager is an inverted fluorescent microscope for live cell multicolor imaging.

Leica EM ICE

Sample preparation instruments

Leica EM ICE

High Pressure Freezing machine

High Pressure Freezing immobilizes aqueous samples in their native state to deliver rapid sample preservation without introducing significant structural alterations.

One move, fully automated specimen loading: The cartridge assembly and the…

Bal-Tech Freeze fracture System BAF 060

Sample preparation instruments

Bal-Tech Freeze fracture System BAF 060

The freeze fracture technique is used as a complementary technique to direct imaging by cryo-TEM, especially for viscous systems, systems containing micron-scale objects as well as cells, tissues and microorganisms which are too thick for plunge freezing (roughly >5-10 µm.)…

LEICA EM GP

Sample preparation instruments

LEICA EM GP

For the preparation of vitrified fluid samples or extremely thin samples for cryo-TEM, including biological suspensions and industrial emulsions in both aqueous and inorganic (non-toxic) solvents.

The Leica EM GP plunge freezes samples into liquid ethane after removing excess…

Thermo Scientific Vitrobot

Sample preparation instruments

Thermo Scientific Vitrobot

An automated plunging system for vitrifying TEM grids for cryo-EM applications. Good vitrification is a crucial step within structural biology applications such as single particle analysis (SPA), cryo electron tomography (cryo-ET), and MicroED. The Thermo Scientific Vitrobot Mark…

Leica EM AFS2 and EM FSP

Sample preparation instruments

Leica EM AFS2 and EM FSP

Freeze Substitution and Low-Temperature Embedding System for Light and Electron Microscopy.

The Leica EM AFS2 performs freeze substitution and progressive lowering of temperature (PLT) techniques and allows low temperature embedding and polymerization of resins.

The Leica EM…

Leica Ultramicrotome EM UC7

Sample preparation instruments

Leica Ultramicrotome EM UC7

The Ultramicrotome Leica EM UC7 provides easy preparation of semi- and ultrathin sections as well as smooth surfaces of biological and industrial samples for TEM, SEM, AFM and LM examination.

Sectioning at room temperature as well as cryogenic temperatures.

Eucentric…

Pelco BioWave Pro+

Sample preparation instruments

Pelco BioWave Pro+

Microwave processing system

The PELCO BioWave Pro+ is a versatile microwave system designed for laboratory use in sample preparation for electron and light microscopy, immunological/confocal/in situ staining/decalcification and tissue fixation.

Enhanced processing of tissue…

Leica EM TP

Sample preparation instruments

Leica EM TP

The Leica EM TP is an instrument used for ﬁxation and dehydration of samples for further treatment. It can be used for resin processing for electron microscopy (EM) and light microscopy (LM). The Leica EM TP consists of a base unit onto which an EM or LM processing outﬁt can be…

Leica VT1000 S Vibrotome

Sample preparation instruments

Leica VT1000 S Vibrotome

The vibrating blade microtome is used to produce monolayer or thick sections of fixed or fresh tissue under physiological conditions without freezing or embedding.

At the EM Unit the device is used mostly for preparing sections of agarose embedded, fixed or unfixed samples for…

Safematic CCU-010 HV

Sample preparation instruments

Safematic CCU-010 HV

High vacuum sputter and carbon coater.

A compact, fully automatic sputter coater and/or carbon coater.

The use of an oil-free, pumping system reduces contamination or defects in the coating to a minimum.

The device can be kept under vacuum when switched off. This…

PELCO easiGlow™

Sample preparation instruments

PELCO easiGlow™

The PELCO easiGlow™ Glow Discharge Cleaning System is a compact, quick and easy to use standalone system. It is primarily designed for cleaning TEM grids and hydrophilization of TEM carbon support films, which have the tendency to be hydrophobic. A glow discharge treatment with…

Evactron® CombiClean™ System

Sample preparation instruments

Evactron® CombiClean™ System

Decontaminate specimens and columns of SEMs and FIBs. The Evactron® CombiClean™ System combines an onboard vacuum cleaning chamber and external PRS (Plasma Radical Source) control in one unified system.

Cleans SEM/TEM samples and SEM chambers from one desktop controller

Store…
